General Specs |
| Color | Stainless Steel |
| Color/Finish Name | Stainless Steel |
| Range Hood Type | Wall Mounted |
| Ventilation Type | Ducted |
| Ventilation Direction | Horizontal |
| Vent Location | Top |
| Grease Filter Type | Baffle |
| Duct Size (in.) | 8" Round |
| Bulb Type | LED |
| Sones Rating | 1.5 - 7 |
| Maximum CFM | 600 |
| Range Hood Features | Light, Automatic Shut Off, Remote Control, Dishwasher Safe Filter |
| Smart Compatible | Yes |
| Appliance Fit Width (in.) | 42 |
| Width (in.) | 42 |
| Height (in.) | 54 |
| Depth (in.) | 20 |
| Collection | 3000 RC Slim Line |
| Series | 3000 RC Slim Line |
| Manufacturer Warranty | 3 Year Parts & Labor |
Specifications |
| Hood Style | Low-Profile |
| CFM | Internal motor models deliver 390 CFM (code compliant) |
| Material | Commercial grade stainless steel (#304 with #4 brush finish) |
| Filters | Two oversized 14” x 15” stainless steel baffle filters improve performance (3 on the 48" model). Dishwasher safe with 2 easy-grip handles. |
| Duct Cover Options | Two-piece, telescopic duct cover to 10′ ceiling included. Optional telescopic duct cover to 12′ ceiling sold separately. |
| Installation | Includes simple wall mount brackets. Wiring diagram label for simple electrical connection. Under cabinet mount option. |
